設備型號 | 磨頭數量 (pcs) |
加工寬度范圍 (mm) |
工作厚度 (mm) |
輸送帶速度 (m/min) |
磨頭電機功率 (kW) |
主傳動 電機功率 (kW) |
擺動電機功率 (kW) |
氣源壓力 (MPa) |
單頭耗氣量 (L/min) |
單頭耗水量(L/min) |
外形尺寸(L×W×H) |
總重 |
---|---|---|---|---|---|---|---|---|---|---|---|---|
NCPJ600/14/16/20 | 14/16/20 | 400-600 | 5-20 | 8-30 | 11 | 11/15/18.5 | 2×3/2×4/4×2.2 | 0.6-0.8 | 20 | 30 | 11798/12787/16342×2301×2360 | 22000/25000/28000 |
NCPJ800/14/16/20 | 14/16/20 | 400-800 | 5-20 | 8-30 | 11 | 11/15/18.5 | 2×3/2×4/4×2.2 | 0.6-0.8 | 20 | 30 | 11798/12787/16342×2563×2360 | 23000/26000/29000 |
NCPJ1000/14/16/20 | 14/16/20 | 500-1000 | 5-20 | 8-30 | 11 | 11/15/18.5 | 2×3/2×4/4×2.2 | 0.6-0.8 | 20 | 30 | 11798/12787/16342×2868×2360 | 24000/27000/30000 |
NCPJ1200/14/16/20 | 14/16/20 | 600-1200 | 5-20 | 8-30 | 11 | 11/15/18.5 | 2×3/2×4/4×2.2 | 0.6-0.8 | 20 | 30 | 11798/12787/16342×3175×2360 | 25000/28000/31000 |
NCPJ1600/16/20 | 16/20 | 1000-1600 | 5-20 | 8-30 | 11 | 15/18.5 | 2×5.5/2×7.5 | 0.6-0.8 | 20 | 30 | 9264/11598/12587/16142×2301×2260 | 20000/22000/25000/28000 |
NCPJ1800/16/20 | 16/20 | 1000-1800 | 5-20 | 8-30 | 11 | 15/18.5 | 4×5.5/4×7.5 | 0.6-0.8 | 20 | 30 | 9264/11598/12587/16142×2563×2260 | 21000/23000/26000/29000 |
NCPJ2000/16 | 16 | 1000-2000 | 5-20 | 8-30 | 11 | 15/18.5 | 2×5.5/2×7.5 | 0.6-0.8 | 20 | 30 | 9264/11598/12587/16142×2868×2260 | 22000/24000/27000/30000 |
